Studio 5000 Logix Designer

Logix SIS Support

• Simple Logix Designer application workflow to enable high availability safety
• Enables a flexible architecture to incorporate Standard and Safety IO in one platform where redundant safety is required

Instruction Toolbox

• Improved on-boarding experience for new Logix Designer application programmers
• Enables a consistent workflow across Rockwell Automation design software

Online Help

• Stay current on support documentation
• Further enable self-help tools for immediate assistance

Simplified OPC UA Workflow

• Reduce configuration effort by removing coding requirements
• Improved ease of troubleshooting and support for OPC UA applications

New Hardware Support

• 1756-RM3

• As an OPC UA server or OPC UA client
• Enable Logix controllers can directly communicate with other third-party automation devices with built-in OPC UA

• Additional Safety Signatures at lower component levels
• Generate a Safety Signature Report for all Safety Signature IDs
• Faster time to market by reducing validation and testing time

• Expanded support for Standard Ladder Logic instruction in Safety.
• Create more code in Safety routines, instead of referencing Standard routines for desired code functionality

• Validate safety code including safety tasks, CIP Safety drive connections, safety feedback, safety attributes, and pass-through safety parameters.
• No dependencies on physical drives during design or testing, reducing overall cost

• Reference each motion axis as a variable
• Create efficient code by using this variable in motion instructions instead of the named axis

• Cut/Copy/Paste to duplicate existing IO in the device tree, including the existing parameters.
• Also available in L5X file

• Harmonize EDS, IO-Link IODD, and HART DD between workstations with new Export feature.
• Import to other workstations to deliver description file consistency.

• 5032 IO-Link
• 1756-L85ES

• Directs PhaseManager™ programs inside a Logix-based controller in an ordered sequence to conduct process-oriented task
• Includes integrated visualization and reporting
• Integrated with FactoryTalk® Batch

• 5580 & 5380 ControlLogix® and GuardLogix®
  • Standard task motion logic, CIP Motion drive connection
• Low Fidelity CIP Motion axis/drive simulation model
  • Kinetix® and PF CIP Motion drives, iTRAK® 5730

• P_D4SD - controls and monitors feedback from a discrete 2-state, 3-state, or 4-state device in various modes, monitoring for fault conditions.
• P_nPos - controls a circular or linear discrete device with 2…30 positions
• P_ValveMP – controls one mix-proof valve in various modes and states and can check position feedback inputs to verify that the valve reached the commanded position.

• Audit Value and ChangesToDetect attributes available to 5x80 Controllers

• FLEXHA 5000™
• 1756-EN4TR Enhancements
• GuardLink®

• CIP Security support in all GuardLogix® 5580, Compact GuardLogix® 5380 platforms and CompactLogix™ 5380

• Now supported in PanelView™ 5000 Studio 5000 View Designer® version 8 and above
• Now supported in PowerFlex® drives
• Now supported in Stratix® Network Switches

• Improved online experience
• Improved download performance
• New Time Data Types
• CIP Security expansion

• Support for the ControlLogix 5580 controller redundant capability, process controllers, no-stored energy controllers, and iTrak 5730.

• Use updated and embedded process instructions, a pre-made task model, instruction usage reports, and highly integrated HART for improved project workflows.

• Send project device diagnostic information directly your FactoryTalk View SE 12 diagnostic frame without additional programming.

• Introducing data preserve download, default FactoryTalk® Linx communications, extended tag properties (AOIs/alarms), display task period, enable/disable embedded webpage, and more.  Includes version 32 feature expansion: 64-bit data types, function block functions.
